Salient features
- Automatic voltage adjustment.
- Wide input voltage range.
- Short circuit & over load protection.
- Output over voltage protection.
- Delay time output.
- Auto – equalized phase, suitable to unstable voltage areas.
- Power: 600VA
- Input: 90V ÷ 240V, 140V ÷ 240V
- Output: 110V - 220V (±3%)
- Frequency: 50Hz/ 60Hz.
- Control system: Servo motor
- Response speed: 2-5V/sec
- Delay: 5 sec
- Over load, short circuit: yes ACB/ MCB/ CB
- Insulation resistance: More than 5MΩ at DC 500V.
- Dielectric strength: Test at 2000VAC/50 Hz for 1 min
- Efficiency: >= 98% changeable according to the input voltage.
- Noise Level: <=40dB
- Temperature: 5-40 degree Celsius.
- Humidity: 20 – 90%
- Dimension: 185 x 355 x 265 mm
