Insulating transformer Classy (Copper wire)

SKU: IT1P400C
Giá gốc 760,000
  • Transformer is designed to applicable technology standard, full loading capacity.
  • Manufactured with silicon steel, incubated in processing with modern technology to the highest performance.
  • Use 100% copper wire or aluminium wire
Contact
  • Transformer is designed to applicable technology standard, full loading capacity.
  • Manufactured with silicon steel, incubated in processing with modern technology to the highest performance.
  • Use 100% copper wire or aluminium wire
  • Product:Insulating transforme
  • Model: Classy series (100% Copper wire)
  • Design power: 400VA, 600VA, 1KVA & 2KVA,
  • Input voltage: 220V or by special order
  • Output voltage: 100V - 120V or by special order
  • Frequency: 50Hz/ 60Hz.
  • Over load short circuit: Fuse / CB / MCB
  • Insutalion resistance: > 5MΩ at 500VDC
  • Dielectric strength: Test at 1500VAC/50Hz for 1 min.
  • Efficiency: ≥ 98%
  • Noise level: <=40dB
  • Ambient Temperature: 5 - 40oC
  • Relative Humidity: 20 - 90%
  • Warranty: 12 months

Model

Design power

Dimensions

IT1P400C

400VA

220 x 150 x 94 mm

IT1P600C

600VA

240 x175 x 110 mm

IT1P1000C

1KVA

245 x 190 x 190 mm

IT1P2000C

2KVA

310 x 215 x 205 mm
