Salient features
- Transformer is designed to applicable technology standard, full loading capacity.
- Manufactured with silicon steel, incubated in processing with modern technology to the highest performance.
- Use 100% copper wire or aluminium wire
Standout Features
- Product: Universal transformer
- Model: Classy series (100% Copper wire)
- Phase: 3 phase
- Design power: 100KVA -500KVA
- Input voltage: 380V, 415V or by special order
- Output voltage: 200V - 220V or by special order
- Frequency: 50Hz/ 60Hz.
- Over load short circuit: Fuse / CB / MCB
- Insutalion resistance: > 5MΩ at 500VDC
- Dielectric strength: Test at 1500VAC/50Hz for 1 min.
- Efficiency: ≥ 98%
- Noise level: <=40dB
- Ambient Temperature: 5 - 40oC
- Relative Humidity: 20 - 90%
- Warranty: 12 months
|
Design power |
Dimensions |
|
100 KVA |
710 x 800 x 800 mm |
|
120 KVA |
710 x 800 x 800 mm |
|
150 KVA |
860 x 900 x 1065 mm |
|
200 KVA |
860 x 900 x 1065 mm |
|
250 KVA |
1110 x 800 x 965 mm |
|
300 KVA |
1110 x 800 x 965 mm |
|
400 KVA |
1510 x 1400 x 1765 mm |
|
500 KVA |
1510 x 1400 x 1765 mm |
